The Wharfedale
Type 4C

Plots 11, 12, 14 & 15

Ground Floor

kitchen / dining = 6700 x 3650mm
lounge = 6500 x 3800mm
garage = 5940 x 3125mm

First Floor

master bedroom 1 = 4600 x 3700mm
dressing room = 1975 x 1420mm
en-suite = 2175 x 1975mm
bathroom = 3825 x 2245mm
bedroom 3 = 3825 x 3400mm
laundry = 2700 x 2200mm

Second Floor

master bedroom 2 = 4600 x 3700mm
dressing room = 1975 x 1420mm
en-suite = 2175 x 1975mm
bathroom = 3825 x 2245mm
bedroom 4 = 3825 x 3400mm
bedroom 5 = 2700 x 2200mm

Kitchen Type 4C

This illustration is just an example of possible layout for kitchen in our house type 4C
